Outstanding Performance
Q23-135E50 diesel engine with turbo intercooler delivers 97kW (135PS) at 3,000 rpm and 345 Nm torque at 2,000 rpm for optimal performance under heavy loads.
Superior Braking System
Dual-circuit hydraulic braking with vacuum assist, front disc brakes, and rear drum brakes for enhanced stopping power and safety.
Enhanced Suspension
Multi-leaf spring suspension with dual-acting shock absorbers provides excellent load support and ride comfort on any terrain.
Safety Innovations
Advanced ABS (Anti-lock Braking System) and ESC (Electronic Stability Control) systems improve stability and control in a variety of driving conditions.
Spacious Cab Design
1,645mm wide cab with ergonomic controls ensures driver comfort during extended hauls.
Fuel Efficiency
Clean & AdBlue-Free: Equipped with latest Euro 5 engines that deliver low emissions and excellent fuel efficiency without the need for AdBlue.
SPECIFICATION
Brand
DFAC
Model Code
VA91-101J
Configuration
4x2
GVW (Gross Vehicle Weight)
3800kg
Maximum Speed
90km/H
Gradeability
51%
Curb Weight
1650kg
Minimum Turning Radius
7.7m
Model
Quanchai, Q23-135E50
Type
Diesel, in-line 4 cyl, Turbo Intercooler
Fuel Injection System
ECU Control Common Rail Injection
Displacement
2307cc
Max. Output
97kW / 135PS @ 3,000rpm
Max. Torque
345Nm @ 2,000rpm
Emission Standards
Euro V with EGR, DOC, POC
Form
Diaphragm Spring
Diameter
Φ265mm
Model
(WLY-5GT32) 5 Speed MT
Gear Ratio
1st
4.714
2nd
2.467
3rd
1.650
4th
1.000
5th
0.719
Reverse
4.505
Cross-sectional Dimensions (mm)
140 x 50 x 4
Width
750mm
Layer
Single Layer
Service Braking system
Dual-circuit hydraulic brakes with vacuum assist
Front Brake
Disc
Rear Brake
Drum
ABS (Antilock Braking System)
Yes
Parking Brake
Mechanical internal-expanding, acting on transmission output shaft
Front
Maker
AAM
Type
Reversed Elliot, I-Beam
Capacity
2,000kg
Rear
Maker
AAM
Type
Full Floating, Pressed welding housing, Hypoid Gear
Capacity
3,000kg
Ratio
4.330
Front
Type
Multi Leaf Spring with Dual Acting Shock Absorber
Number of Springs
3
Rear
Type
Multi Leaf Spring with Dual Acting Shock Absorber
Number of Springs
5 main springs
Wheel Type
6 Stud Tubeless Tires
Wheel Size
195/75R15LT
Rim Size
5.50J
Number of Tires
4 + 1
Cab Type
Single Row
Cab Width
1645mm
Steering
Recirculating ball with Hydraulic power assistance
Power Window
Yes
Central Locking
Yes
Battery
12V, 100AH
Alternator
14V - 120A
Capacity
80L
Material
Steel
Wheelbase (WB)
2,800mm
Overall Length (OL)
5,267mm
Overall Width (OW)
1,645mm
Overall Height (OH)
2,010mm
Front Overhang (FOH)
1,140mm
Rear Overhang (ROH)
1,327mm
Front Track (FT)
1,400mm
Rear Track (RT)
1,380mm
